8 Stand ropes
|
|
Product Id: 8 Stand ropes
Overview
With our experience in rope making and strength in yarn extrusion, we have introduced tailor made products for specific applications.
- GARFIL MAXIMA
- GARFIL MAXIFLEX
- GARFIL MAXIFLEX SUPER
- GARFIL MAXIGOLD
GARFIL MAXIMA:
These premium ropes are produced from blended polymers with special lay for low weight & high strength.
Product Features
- Approx. 40% more strength than conventional Polypropylene ropes.
- Special blend of raw materials ensures excellent abrasion resistance.
- Better value for money as compared to conventional ropes.
- Weight to strength ratio is less, facilitating down sizing vis-à-vis PP ropes.
- Unaffected by acids and alkalis.
Garfil MAXIFLEX:
These ropes are of composite fiber construction made from high tenacity polyester and polypropylene yarn in a specific composition.
Product Features
- Specific gravity is equivalent to Nylon.
- Higher strength compared to Nylon.
- No loss of breaking strength in wet conditions.
- A multifilament cover ensures excellent abrasion resistance.
- Retains flexibility even after prolonged use.
- Controlled elongation and high-energy absorption.
- Cost effective and less weight per meter as compared to Nylon.
- The ropes can also be supplied as per OCIMF guidelines.
| SIZES |
Garfil Maxima |
Garfil Maxiflex |
CIRCUMFERENCE
(Inch) |
DIAMETER
(mm) |
Wt. /Coil of
220 mtr. in Kgs |
Breaking
Strength Kgf
| Wt./Coil of
220 mtr. in Kgs |
Breaking
Strength Kgf |
| 3.00 |
24.00 |
57 |
10500 |
70 |
12000 |
| 3.50 |
28.00 |
78 |
14500 |
96 |
15800 |
| 4.00 |
32.00 |
101 |
18500 |
124 |
20000 |
| 4.50 |
36.00 |
129 |
23250 |
157 |
24900 |
| 5.00 |
40.00 |
158 |
28000 |
195 |
30000 |
| 5.50 |
44.00 |
194 |
34000 |
238 |
35800 |
| 6.00 |
48.00 |
229 |
39500 |
282 |
46290 |
| 6.50 |
52.00 |
268 |
45500 |
330 |
54300 |
| 7.00 |
56.00 |
312 |
52000 |
378 |
62800 |
| 7.50 |
60.00 |
359 |
59500 |
438 |
72000 |
| 8.00 |
64.00 |
407 |
67550 |
495 |
82600 |
| 9.00 |
72.00 |
515 |
84500 |
627 |
102000 |
| 10.00 |
80.00 |
638 |
104000 |
775 |
125500 |
| 11.00 |
88.00 |
772 |
125000 |
1100 |
156000 |
| 12.00 |
96.00 |
916 |
148000 |
1315 |
185000 |
| 13.00 |
104.00 |
1075 |
173500 |
1540 |
216000 |
| 14.00 |
112.00 |
1250 |
201000 |
1790 |
250000 |
| 15.00 |
120.00 |
1435 |
230000 |
2050 |
286000 |
|
GARFIL MAXIFLEX SUPER
GARFIL MAXIGOLD
Garfil Ropes Packaging details
Standard coils are available in 165 meters / 220 meters lengths with eyes at both ends. Custom-made package size and length can be manufactured according to specific requirements.
8 Strand Rope Applications:
These ropes are ideal for all marine applications, namely:
- Mooring Lines
- Towing Lines
- On Board Oil Rigs
- SPM Hawsers
- Oil Exploration
Specifications:
- All values listed are as per results confirmed in accordance to test procedures of BSEN 919.
- Weights are subject to + /- 5% variation.
- All Specifications pertain to regular laid ropes and are applicable only to new ropes.
- The products indicated in this brochure do not constitute the whole range of GWRL products.
- Please contact us if other sizes and characteristics are required.
- GWRL reserves the right to review its product specifications
|
|
|
|
